Barrel nipple is a type of pipe fitting used in plumbing and industrial applications. It is a short piece of pipe with male threads on both ends, designed to connect two pipes together.
Where To Use Barrel Nipple
Industrial applications where pipes need to be connected quickly and easily.
Plumbing systems where a temporary or emergency connection is needed.
Piping systems in the oil and gas industry, where high-pressure connections are required.
Key Features Of Barrel Nipple
Male threads on both ends for easy connection.
Short length, typically between 1-3 inches.
Available in various materials, including steel, brass, and copper.
How To Use Barrel Nipple
Choose the correct size and material for your application.
Clean and prepare the pipe ends before assembly.
Tighten the barrel nipple securely to ensure a leak-free connection.
How Barrel Nipple Is Manufactured
Barrel nipples are typically manufactured using a combination of machining and casting processes. The material is first cast into a cylindrical shape, then machined to create the male threads on both ends.
Technical Specification Of Barrel Nipple
Specification
Description
Material
Steel (ASTM A106 Grade B)
Size
1-1/2" NPS (Nominal Pipe Size)
Length
3 inches (76 mm)
Thread Type
NPT (National Pipe Tapered)
Pressure Rating
2500 psi (17.2 bar) at 100°F (38°C)
The technical specification of barrel nipple includes details such as material, size, length, thread type, and pressure rating. The specified material is steel (ASTM A106 Grade B), with a size of 1-1/2" NPS and a length of 3 inches. The thread type is NPT (National Pipe Tapered), and the maximum operating pressure is 2500 psi at 100°F (38°C). It's essential to follow these specifications when selecting or manufacturing barrel nipples for specific applications.
Description Of Barrel Nipple
The barrel nipple is a versatile and crucial component in various industrial and plumbing applications. Its primary function is to connect two pipes together quickly and easily, making it an essential tool for emergency or temporary connections.
Related Products & Synonyms Of Barrel Nipple
Barrel nipples are often related to other pipe fittings and components, such as pipe adapters, elbows, and tees. Some synonyms for barrel nipple include pipe connector, pipe coupling, and pipe adapter.
