Bellow seals, also known as bellows or expansion joints, are flexible components used to absorb vibrations and movements in piping systems, valves, and equipment. They consist of a hollow tube with a bellows-like structure, allowing for flexibility and expansion while maintaining a seal.
Where To Use Bellow Seals
Bellow seals are widely used in various industries, including chemical processing, power generation, oil and gas refining, and water treatment. They can be found in applications such as piping systems, valve assemblies, and equipment mounts.
Key Features Of Bellow Seals
Flexible design for absorbing vibrations and movements
Hollow tube construction for easy installation and maintenance
Durable materials for long-lasting performance
Sealable design to prevent fluid leakage
Available in various sizes and configurations
How To Use Bellow Seals
Inspect the bellow seal for any signs of damage or wear
Clean the surrounding area to ensure a proper seal
Install the bellow seal according to manufacturer's instructions
Tighten the bolts securely to prevent leaks
Monitor the system for any signs of leakage or damage
How Bellow Seals Is Manufactured
Bellow seals are manufactured using high-quality materials, such as steel, stainless steel, and rubber. The production process involves shaping the material into a hollow tube, then forming the bellows-like structure through a combination of machining and assembly.
Technical Specification Of Bellow Seals
Inner Diameter (mm)
50-200
Outer Diameter (mm)
60-250
Width (mm)
10-50
Material
Steel, Stainless Steel, Rubber
The specifications of bellow seals are designed to accommodate various piping and equipment applications. The inner diameter, outer diameter, and width are tailored to meet specific requirements, while the material selection ensures durability and resistance to corrosion.
Description Of Bellow Seals
Bellow seals are designed to provide a flexible and sealable connection between pipes, valves, and equipment. They absorb vibrations and movements, preventing fluid leakage and ensuring smooth operation.
Related Products & Synonyms Of Bellow Seals
The following products are related to bellow seals:
