Din rail is a type of mounting system used for electrical devices, such as circuit breakers, contactors, and timers. It consists of a rail with holes or slots where the devices can be mounted. Din rail is commonly used in industrial settings to provide a safe and organized way to mount electrical equipment.
Where To Use Din Rail
Din rail can be used in a variety of applications, including industrial control panels, switchboards, and distribution boards. It is also commonly used in building management systems and data centers.
Key Features Of Din Rail
Mounting system for electrical devices
Consists of a rail with holes or slots
Provides safe and organized way to mount equipment
Commonly used in industrial settings
How To Use Din Rail
Identify the devices to be mounted on the din rail
Select the appropriate type of din rail based on device size and weight
Mount the devices on the din rail using screws or clips
Ensure secure and stable mounting
How Din Rail Is Manufactured
Din rail is typically manufactured from steel or aluminum using a process of extrusion, cutting, and drilling. The material is then coated with a protective layer to prevent corrosion.
Technical Specification Of Din Rail
Material:
Steel or Aluminum
Length:
Customizable up to 3 meters
Width:
16 mm, 20 mm, or 25 mm
Thickness:
1.5 mm, 2 mm, or 3 mm
Mount Type:
Screw, Clip, or Adhesive
The technical specification of din rail is designed to provide a safe and reliable mounting system for electrical devices. The material, length, width, thickness, and mount type can be customized to suit specific requirements.
Description Of Din Rail
Din rail is a versatile and widely used mounting system for electrical devices. Its compact design and customizable features make it an ideal choice for industrial control panels, switchboards, and distribution boards.
Related Products & Synonyms Of Din Rail
Din rail is related to other mounting systems such as:
