A flange yoke is a crucial component in the automotive industry, specifically designed for connecting rods and crankshafts. It plays a vital role in transferring rotational motion from the crankshaft to the connecting rods.
Where To Use Flange Yoke
Automotive engines, particularly in high-performance applications
Mechanical devices requiring precise rotational motion transfer
Industrial equipment, such as generators and pumps
Key Features Of Flange Yoke
Forged or cast construction for enhanced strength and durability
Machined surfaces for precise fitment and reduced wear
Designed to withstand high torques and stresses
Available in various materials, including steel and aluminum
How To Use Flange Yoke
Mount the flange yoke to the crankshaft using bolts or screws
Position the connecting rods on the flange yoke, ensuring proper alignment
Tighten the bolts or screws securely to prevent loosening under stress
Regularly inspect and maintain the flange yoke for signs of wear or damage
How Flange Yoke Is Manufactured
The manufacturing process for flange yokes involves several stages, including raw material selection, forging or casting, machining, and quality control. The exact process may vary depending on the manufacturer and specific design requirements.
Technical Specification Of Flange Yoke
Material:
Steel (EN24 or equivalent)
Flange Diameter:
40mm to 80mm
Torque Capacity:
500Nm to 2000Nm
Surface Finish:
Machined surface with Ra 1.6?m
Dimensions (L x W x H):
120mm x 60mm x 30mm
Temperature Range:
-20°C to 120°C
The technical specification of a flange yoke is critical in determining its suitability for specific applications. The material, flange diameter, torque capacity, surface finish, dimensions, and temperature range are all important factors that affect the performance and lifespan of the component.
Description Of Flange Yoke
A flange yoke is a precision-engineered component designed to transmit rotational motion from the crankshaft to the connecting rods in automotive engines.
