Flanged fitting is a type of pipe connector that features flanges on both ends, allowing for easy connection and disconnection from other pipes or fittings. It is commonly used in various industrial applications where high-pressure connections are required.
Where To Use Flanged Fitting
Flanged fittings are used in various industries such as oil and gas, chemical processing, power generation, and water treatment. They are ideal for applications where high-pressure connections are necessary, such as between pipes, pumps, valves, or other equipment.
Key Features Of Flanged Fitting
Flanges on both ends for easy connection and disconnection
High-pressure rating for demanding applications
Durable construction to withstand harsh environments
Easy installation and maintenance
How To Use Flanged Fitting
Ensure proper installation of flanges and gaskets
Tighten bolts securely to maintain pressure rating
Maintain regular inspections for signs of wear or damage
Replace worn-out parts promptly to prevent leaks or failures
How Flanged Fitting Is Manufactured
The manufacturing process of flanged fittings involves several steps including material selection, forging or casting, machining, and quality control. The materials used are typically metals such as steel, stainless steel, or bronze, which provide the necessary strength and durability for high-pressure applications.
Technical Specification Of Flanged Fitting
Material:
Carbon Steel
Size:
1-1/2" to 48"
Pressure Rating:
Class 150 to Class 2500
Thickness:
1/16" to 2"
Temperature Rating:
-20°F to 1000°F (-29°C to 538°C)
The technical specifications of flanged fittings are crucial in ensuring proper selection and installation for specific applications. The material, size, pressure rating, thickness, and temperature rating must be carefully considered to meet the requirements of the particular industry or process.
Description Of Flanged Fitting
A flanged fitting is a type of pipe connector that features flanges on both ends, allowing for easy connection and disconnection from other pipes or fittings. It consists of two flanges with bolt holes and a gasket between them, which provides a tight seal when tightened.
Related Products & Synonyms Of Flanged Fitting
The related products of flanged fittings include other types of pipe connectors, such as weld neck flanges and slip-on flanges, while the synonyms are flanged pipe fittings and flanged pipe accessories.
