Heat shrink terminal is a type of electrical connector used to join two or more wires together. It is made from heat-shrinkable plastic material that shrinks when exposed to heat, providing a secure and waterproof connection.
Where To Use Heat Shrink Terminal
Heat shrink terminals are used in various electrical applications, including cable assemblies, wiring harnesses, and circuit boards.
They are suitable for use in harsh environments, such as high-temperature or chemical exposure areas.
Key Features Of Heat Shrink Terminal
Heat-shrinkable plastic material for secure and waterproof connection.
Easily installable with a heat source, such as a soldering iron or heat gun.
Available in various sizes to accommodate different wire diameters.
How To Use Heat Shrink Terminal
Clean the wire ends to be connected.
Slip the heat shrink terminal over one end of the wire.
Apply heat to the terminal until it shrinks and secures itself to the wire.
How Heat Shrink Terminal Is Manufactured
Heat shrink terminals are manufactured using a process that involves extruding the heat-shrinkable plastic material into a desired shape and size. The material is then cut to length and packaged for distribution.
Technical Specification Of Heat Shrink Terminal
Cable Size:
AWG 20-30
Insulation Material:
PTFE (Teflon)
Color:
Black, Red, Blue
Temperature Rating:
-40°C to +120°C
The technical specifications of heat shrink terminals are designed to provide a secure and reliable connection in various electrical applications. The cable size range is AWG 20-30, with insulation material PTFE (Teflon) for excellent chemical resistance. The color options include black, red, and blue, while the temperature rating ranges from -40°C to +120°C.
Description Of Heat Shrink Terminal
Heat shrink terminals are an essential component in electrical connections, providing a secure and waterproof connection between wires. They are made from heat-shrinkable plastic material that shrinks when exposed to heat, ensuring a reliable connection.
Related Products & Synonyms Of Heat Shrink Terminal
Heat shrink connectors are similar to heat shrink terminals but have a different design and application.
Shrink tubing is another type of electrical connector that uses heat-shrinkable plastic material for a secure connection.
