A level glass indicator is a precise instrument used to measure the level of liquids in tanks, containers, or pipes. It consists of a transparent tube filled with a colored liquid and marked with graduation lines indicating various levels. The user can read the liquid's level by observing the meniscus (the curved surface) formed by the liquid within the tube.
Where To Use Level Glass Indicator
Level glass indicators are commonly used in various industrial settings, including chemical plants, oil refineries, and water treatment facilities, to monitor the level of liquids during processing or storage.
Key Features Of Level Glass Indicator
High accuracy and precision in measuring liquid levels
Durable construction to withstand harsh industrial environments
Easy-to-read graduation lines for clear level indication
Wide range of materials available for customization (e.g., stainless steel, brass)
How To Use Level Glass Indicator
Place the level glass indicator near the liquid container or tank
Align the tube's viewing end with the surface of the liquid
Read the level indication by observing the meniscus formed within the tube
Ensure accurate readings by calibrating the instrument periodically
How Level Glass Indicator Is Manufactured
The manufacturing process involves several steps, including cutting and shaping the glass tube to precise dimensions, calibrating the graduation lines with high accuracy, and assembling the indicator's components (e.g., mounting hardware). The materials used for construction are carefully selected based on their durability and resistance to corrosion.
Technical Specification Of Level Glass Indicator
Frame Material:
Stainless Steel (304 or 316)
Type of Glass:
Borosilicate or Soda-Lime
Connection Type:
Threaded, Flanged, or Welded
Mounting Type:
Clamp, Bracket, or Screw Mount
Brand:
Hanna Instruments, Meriam Instrument Company
The technical specifications listed above are based on common industry standards and may vary depending on the specific requirements of the application. It is essential to consult with the manufacturer or a qualified engineer to determine the most suitable configuration for your needs.
Description Of Level Glass Indicator
A level glass indicator is an indispensable tool for ensuring accurate and reliable measurement of liquid levels in various industrial applications.
Related Products & Synonyms Of Level Glass Indicator
Synonyms for level glass indicators include:
Float Glass Level Gauge
Bubble Tube Level Indicator
Cryogenic Liquid Level Indicator
These products are designed for specific applications and offer varying levels of accuracy, durability, and functionality.
