Liquid filled gauges are pressure measuring instruments that utilize a liquid column to indicate pressure levels. The gauge is designed to measure pressures in various industrial applications, and it is an essential tool for monitoring and controlling processes.
Where To Use Liquid Filled Gauges
Liquid filled gauges can be used in various industrial settings, including power plants, chemical processing facilities, and oil refineries. They are also used in laboratories and research institutions to measure pressures in experimental setups.
Key Features Of Liquid Filled Gauges
High accuracy and reliability
Durable construction for long-lasting performance
Wide range of pressure measurement capabilities
Easy to read dial face with clear markings
Robust mounting options for secure installation
How To Use Liquid Filled Gauges
Mount the gauge securely to the measurement surface using the provided mounting hardware
Connect the gauge to the process line or fluid source as required
Set the zero point of the gauge by adjusting the internal calibration screw
Take readings from the dial face, ensuring accurate measurement within the gauge's pressure range
How Liquid Filled Gauges Is Manufactured
The manufacturing process for liquid filled gauges involves several stages, including design and prototyping, material selection and procurement, assembly and calibration, and quality control checks.
Technical Specification Of Liquid Filled Gauges
Pressure Range:
0-10 bar
Accuracy:
±2% of full scale
Dial Size:
100 mm diameter
Connection Size:
1/2" NPT
Mounting Type:
DIN 43351 mounting bracket
Operating Temperature Range:
-20°C to +60°C
Case Material:
Stainless steel (304)
Fill Fluid:
Mineral oil
The technical specification of the liquid filled gauges is designed to provide a clear understanding of its performance and capabilities. The gauge's pressure range, accuracy, dial size, connection size, mounting type, operating temperature range, case material, and fill fluid are all specified to ensure optimal functionality in various industrial applications.
Description Of Liquid Filled Gauges
Liquid filled gauges are designed to provide accurate and reliable pressure measurement in a wide range of industrial applications. The gauge's robust construction and durable materials ensure long-lasting performance, making it an essential tool for monitoring and controlling processes.
Related Products & Synonyms Of Liquid Filled Gauges
The related products of liquid filled gauges include other pressure measurement instruments, such as bourdon tube gauges and capsule type gauges. The synonyms for liquid filled gauges are liquid pressure gauges.
