A magnetic gauge is a device used to measure the level or pressure of a fluid in a tank or container. It works on the principle of magnetism, where a float is attached to a magnetic rod and moves up or down depending on the level of the fluid.
Where To Use Magnetic Gauge
Magnetic gauges are commonly used in industries such as oil and gas, chemical processing, and power generation. They are ideal for measuring the level of fluids in tanks, vessels, and pipelines.
Key Features Of Magnetic Gauge
High accuracy and reliability
Wide temperature range
Corrosion-resistant materials
Easy installation and maintenance
How To Use Magnetic Gauge
Install the gauge in a suitable location
Carefully calibrate the gauge according to the manufacturer's instructions
Regularly check and maintain the gauge to ensure accurate readings
How Magnetic Gauge Is Manufactured
The manufacturing process of magnetic gauges involves several stages, including design, material selection, and assembly. The gauges are typically made from corrosion-resistant materials such as stainless steel or brass.
Technical Specification Of Magnetic Gauge
Float Material:
Stainless Steel
Float Design:
Spherical
Chamber Type:
Hermetic
Indicator Type:
Magnetic
Mounting Options:
Threaded and Flanged
Process Connection:
1/2" NPT
Temperature Rating:
-20°C to 100°C
The technical specification of the magnetic gauge provides detailed information about its design and functionality. The float material is made from stainless steel, which ensures corrosion resistance and durability. The spherical float design allows for accurate measurement of fluid levels. The hermetic chamber type prevents gas leakage and contamination. The magnetic indicator type provides a clear visual indication of the fluid level. The threaded and flanged mounting options allow for easy installation on various types of vessels and pipelines. The 1/2" NPT process connection ensures compatibility with standard pipe fittings. The temperature rating of -20°C to 100°C allows for operation in a wide range of environmental conditions.
Description Of Magnetic Gauge
The magnetic gauge is a compact and rugged device designed for measuring fluid levels in tanks, vessels, and pipelines. It consists of a float attached to a magnetic rod, which moves up or down depending on the level of the fluid. The gauge provides accurate and reliable measurements, making it an essential tool for process control and monitoring.
Related Products & Synonyms Of Magnetic Gauge
Some related products of the magnetic gauge include pressure gauges, level sensors, and flow meters. These devices are used for measuring various process parameters such as pressure, temperature, and flow rate.
The synonyms of magnetic gauge include magnetic gage, magnetic level indicator, and magnetic float gauge. These terms are often used interchangeably to refer to the same device or concept.
