A modular slip ring is an electrical device designed to transfer power and signals between two rotating parts, such as a motor and a generator or a sensor and a control system. It consists of a series of insulated contacts that are mounted on a rotating shaft, allowing for the transmission of electrical current while maintaining mechanical integrity.
Where To Use Modular Slip Ring
Applications where high-speed rotation is involved, such as in industrial motors, generators, and gearboxes.
Systems requiring high power transfer rates, such as in electrical distribution panels or data centers.
Environments with high levels of vibration or shock, making traditional connectors unreliable.
Key Features Of Modular Slip Ring
High-speed rotation capabilities up to 10,000 RPM.
High-power transfer rates up to 200 A per contact.
Insulation resistance up to 1000 M? per contact.
Low electromagnetic interference (EMI) and radio-frequency interference (RFI).
How To Use Modular Slip Ring
Mount the modular slip ring to a rotating shaft using a secure fastening system.
Connect power and signal cables to the corresponding contacts on the modular slip ring.
Ensure proper alignment and clearance between the modular slip ring and adjacent components.
How Modular Slip Ring Is Manufactured
The manufacturing process for modular slip rings involves several stages, including design and prototype development, tooling and molding, assembly and testing.
Technical Specification Of Modular Slip Ring
Current Rating (A)
Up to 200 A per contact
Number of Circuits
Up to 10 contacts per ring
Contact Material
Copper or silver-plated contacts for high conductivity
Speed Rating (RPM)
Up to 10,000 RPM
Ingress Protection (IP)
IP67 or higher for dust and water protection
The technical specification of modular slip rings is designed to provide high-performance electrical connections in a wide range of industrial applications. The devices are engineered to meet the demands of high-speed rotation, high-power transfer rates, and reliable operation in harsh environments.
Description Of Modular Slip Ring
A modular slip ring is a compact and highly reliable electrical device designed to transfer power and signals between two rotating parts. It consists of a series of insulated contacts mounted on a rotating shaft, allowing for high-speed rotation and high-power transfer rates while maintaining mechanical integrity.
Related Products & Synonyms Of Modular Slip Ring
The modular slip ring is often used in conjunction with other electrical components, such as motors, generators, and gearboxes.
