A pin header is a type of electrical connector used to connect printed circuit boards (PCBs) or other electronic components.
Where To Use Pin Header
Pin headers are commonly used in a variety of applications, including:
Electronic devices such as computers, smartphones, and televisions
Automotive systems, including lighting, audio, and electrical accessories
Industrial control panels and machinery
Medical equipment, including diagnostic tools and patient monitoring systems
Key Features Of Pin Header
High-quality connectors with durable construction and reliable connections
Various pin counts, pitches, and mounting types to suit different applications
Compact design for space-saving installations
Easy-to-use interface for simplified connection and disconnection
How To Use Pin Header
Identify the correct pin header for your application based on pin count, pitch, and mounting type
Carefully insert the connector into the PCB or other component
Securely fasten the connector using screws, clips, or other attachment methods
Verify the connection is secure and functional before powering up the device
How Pin Header Is Manufactured
The manufacturing process for pin headers typically involves a combination of machine-based and hand-finished operations, including:
Metal stamping or machining to create the connector's base material
Electroplating or other surface treatment methods for enhanced durability
Quality control checks to ensure reliability and performance
Technical Specification Of Pin Header
Pin Count:
50-200 pins
Pitch:
0.5-2.54mm
Mounting Type:
Through-hole, SMD, or press-fit
Current Rating:
Up to 10A per pin
Plastic Height:
2-10mm
The technical specifications outlined above are general guidelines and may vary depending on the specific application and requirements of the pin header. It's essential to consult the manufacturer's documentation or contact a qualified engineer for more detailed information.
Description Of Pin Header
The pin header is a versatile and reliable electrical connector designed for a wide range of applications, from consumer electronics to industrial control systems. Its compact design, combined with high-quality construction and durable materials, makes it an ideal choice for various industries.
Related Products & Synonyms Of Pin Header
Some related products to the pin header include:
Socket headers
Pin sockets
Headers with screws or clips for secure attachment
High-current connectors for applications requiring higher power transmission
