A plane table set is a precision surveying tool used to measure and map large areas with high accuracy. It consists of a wooden or metal frame, a tripod, and a rotating circle with a measuring scale. The user rotates the circle to align it with a reference point, then reads the measurement on the scale.
Where To Use Plane Table Set
Plane table sets are used in various industries, including construction, mining, and engineering. They can be deployed on-site for surveys, mapping, or monitoring projects that require high accuracy measurements.
Key Features Of Plane Table Set
High precision measurements
Durable and weather-resistant construction
Adjustable tripod for stability
Rotating circle with measuring scale
Compact design for easy transportation
How To Use Plane Table Set
Set up the tripod and plane table on a stable surface
Read the measurement on the scale and record it
Repeat the process for multiple measurements
Analyze data using specialized software or instruments
How Plane Table Set Is Manufactured
The manufacturing process involves several stages, including design and prototyping, material selection and procurement, cutting and assembly, quality control, and packaging.
Technical Specification Of Plane Table Set
Table Size:
900mm x 1200mm
Material:
Durable steel alloy
Weight:
15kg
Tripod Height:
1200mm
Leveling Accuracy:
±1mm/m
The technical specifications of the plane table set are carefully designed to ensure high accuracy and durability. The table size is 900mm x 1200mm, made from durable steel alloy material, weighing 15kg. The tripod height is adjustable up to 1200mm, ensuring stability on uneven terrain. The leveling accuracy is ±1mm/m, allowing for precise measurements.
