A recoil spring is a type of coil spring designed to absorb and store energy during the return stroke of an engine or other mechanical device.
Where To Use Recoil Spring
Automotive industry: recoil springs are used in various engine components such as valve trains, rocker arms, and suspension systems.
Aerospace industry: recoil springs are used in aircraft engines and other mechanical systems that require high energy absorption capabilities.
Industrial machinery: recoil springs are used in various industrial applications such as textile machines, printing presses, and power transmission equipment.
Key Features Of Recoil Spring
High energy absorption capacity.
Low friction and wear characteristics.
Long lifespan due to high fatigue resistance.
Compact design suitable for space-constrained applications.
How To Use Recoil Spring
Mount the recoil spring on a suitable support or foundation.
Attach the loading end to the moving part of the system (e.g. valve train, rocker arm).
Ensure proper alignment and clearance between the recoil spring and surrounding components.
How Recoil Spring Is Manufactured
Recoil springs are manufactured using high-grade steel wire, which is wound into a coil shape on a machine. The coils are then inspected for defects and packaged for shipping.
Technical Specification Of Recoil Spring
Material:
High-grade steel (e.g. AISI 5160, 6150)
Spring Type:
Coil spring with helical wound wire
Wire Diameter:
3-12 mm (0.125-0.5 in)
Spring Free Length:
100-800 mm (3.9-31.5 in)
Operating Temperature Range:
-20°C to +150°C (-4°F to +302°F)
Load Capacity:
Up to 10,000 N (2,248 lbf)
The recoil spring is designed to withstand a wide range of operating conditions, including temperature fluctuations and mechanical stresses. The specifications listed above are typical for high-performance recoil springs used in industrial applications.
Description Of Recoil Spring
A recoil spring is a type of coil spring designed to absorb and store energy during the return stroke of an engine or other mechanical device.
Related Products & Synonyms Of Recoil Spring
Related products:
Valve springs
Rocker arm springs
Suspension springs
Compression springs
The synonyms for recoil spring include coil spring, helical spring, and compression spring.
