Surface mount LEDs (Light Emitting Diodes) are a type of semiconductor device that emits light when an electric current passes through it. They are designed to be mounted on the surface of a printed circuit board, hence the name.
Where To Use Surface Mount Led
Surface mount LEDs are used in a variety of applications, including:
Automotive lighting
Aerospace and defense systems
Medical devices
Consumer electronics
Key Features Of Surface Mount Led
High brightness and efficiency
Small size and weight
Long lifespan and reliability
Low power consumption
Wide range of colors available
How To Use Surface Mount Led
Mount the LED on a printed circuit board using a suitable soldering technique
Connect the LED to a power source and control circuit
Adjust the current and voltage levels according to the specifications of the LED
How Surface Mount Led Is Manufactured
Surface mount LEDs are manufactured using a combination of semiconductor and assembly processes. The manufacturing process involves:
Semiconductor fabrication
Wafering and cutting
Die bonding and wire bonding
Molding and packaging
Technical Specification Of Surface Mount Led
Parameter
Specification
Voltage (V)
3.2-3.4
Current (A)
0.01-0.05
Color Temperature (K)
2000-2500
Luminous Flux (lm)
10-50
Viewing Angle (°)
120-180
The technical specifications of a surface mount LED include voltage, current, color temperature, luminous flux, and viewing angle. These parameters are critical in determining the performance and efficiency of the LED.
