A tubular level gauge is a precision instrument used to measure the level of liquids in containers, such as tanks or vats. It consists of a transparent tube filled with a liquid that rises or falls according to the level of the fluid being measured.
Where To Use Tubular Level Gauge
Tubular level gauges are commonly used in various industries, including chemical processing, oil refining, and water treatment. They can be employed in applications where precise measurement of liquid levels is critical, such as in monitoring the level of chemicals or fuels.
Key Features Of Tubular Level Gauge
Accurate measurement of liquid levels
Transparent tube for clear visibility
Filled with a calibrated liquid that rises or falls according to the level being measured
Durable construction for long-term use
How To Use Tubular Level Gauge
Mount the tubular level gauge securely to the container or tank
Familiarize yourself with the calibration markings on the tube
Read the level measurement directly from the tube, taking into account any temperature corrections
Regularly inspect and maintain the instrument for accuracy and proper function
How Tubular Level Gauge Is Manufactured
The manufacturing process for tubular level gauges involves several steps, including material selection and processing, tube fabrication, calibration, and quality control. The materials used are typically high-quality glass or stainless steel to ensure durability and resistance to corrosion.
Technical Specification Of Tubular Level Gauge
Tube Length:
Customizable lengths available, up to 10 meters
Tube Material:
High-quality glass or stainless steel
Tube Diameter:
Available in diameters ranging from 10mm to 50mm
End Connection Type:
Threaded, flanged, or sanitary connections available
Mounting Type:
Adhesive, clamp, or weld-on mounting options
Operating Temperature Range:
-20°C to 200°C (varies depending on material)
The technical specifications of the tubular level gauge are critical for ensuring accurate measurement and reliable operation. The instrument's tube length, material, diameter, end connection type, mounting type, and operating temperature range must be carefully selected to match the specific requirements of the application.
Description Of Tubular Level Gauge
A tubular level gauge is a compact, precision instrument designed for measuring the level of liquids in containers. Its transparent tube and calibrated liquid ensure accurate readings, making it an essential tool in various industries.
Related Products & Synonyms Of Tubular Level Gauge
The tubular level gauge is related to other precision instruments, such as level indicators and gauges. Some synonyms for the tubular level gauge include:
Tubular Level Indicator
Tubular Level Gage
Tube Level Gauges
Tubular Levelling Indicator
These related products and synonyms offer alternative solutions for measuring liquid levels, each with its own unique features and applications.
