Ultrasonic thickness gauges are non-destructive testing devices used to measure the thickness of materials, particularly in industrial and construction settings.
Where To Use Ultrasonic Thickness Gauges
These gauges are commonly used in a variety of industries, including oil and gas, chemical processing, power generation, aerospace, and construction.
Key Features Of Ultrasonic Thickness Gauges
Non-destructive testing
High accuracy and precision
Easy to use and operate
Rugged and durable design
Low maintenance requirements
How To Use Ultrasonic Thickness Gauges
Place the gauge on the surface of the material to be measured
Select the correct measurement range and mode
Adjust the probe as necessary for optimal results
Record the measurements and compare with established standards
How Ultrasonic Thickness Gauges Is Manufactured
The manufacturing process involves a combination of electronic and mechanical components, including circuit boards, microprocessors, and precision engineering.
Technical Specification Of Ultrasonic Thickness Gauges
Measurement Range:
0-200mm, 0-500mm
Frequency:
2-10MHz, 5-20MHz
Probe Type:
Pencil probe, Contact probe
Display Type:
LCD display, Backlit LCD
Connectivity:
USB, Bluetooth
Operating Temperature Range:
-20°C to 60°C, -40°C to 80°C
Battery Type:
Rechargeable lithium-ion, Alkaline
The technical specifications of the ultrasonic thickness gauges are designed to provide accurate and reliable measurements in a variety of applications. The measurement range and frequency options allow for flexibility in measuring different types of materials and surfaces. The probe type and display type ensure ease of use and visibility, while the connectivity options enable easy data transfer and storage. The operating temperature range and battery type ensure durability and long-term use.
Description Of Ultrasonic Thickness Gauges
The ultrasonic thickness gauges are designed to provide accurate and reliable measurements of material thickness, with a focus on industrial and construction applications.
Related Products & Synonyms Of Ultrasonic Thickness Gauges
The related products include other types of non-destructive testing equipment, such as ultrasonic flaw detectors and eddy current testing instruments. The synonyms for the ultrasonic thickness gauges include ultrasonic thickness meters, D meters, pocket D meters, ut gauging machines, and ultrasonic wall thickness gauges.
