Vacuum flanges are specialized piping components designed for high-vacuum applications. They are used to connect pipes or fittings in systems where a vacuum environment is required, such as in vacuum chambers, pumps, or other equipment that operates under low-pressure conditions.
Where To Use Vacuum Flanges
Vacuum flanges are commonly used in various industries, including:
Petrochemical and chemical processing
Aerospace engineering
Scientific research facilities
Industrial equipment manufacturing
Key Features Of Vacuum Flanges
Specialized design for high-vacuum applications
High-purity materials to prevent contamination
Low-outgassing properties to minimize vacuum degradation
Easy installation and connection methods
How To Use Vacuum Flanges
Ensure proper cleaning and surface preparation before installation
Apply suitable lubricants to ensure smooth connection and sealing
Avoid over-tightening, which can lead to flange damage or gasket failure
Maintain regular inspection and maintenance schedules
How Vacuum Flanges Is Manufactured
Vacuum flanges are typically manufactured using high-quality materials, such as stainless steel or other corrosion-resistant alloys. The manufacturing process involves precision machining and assembly techniques to ensure precise fits and smooth connections.
Technical Specification Of Vacuum Flanges
Material:
Stainless Steel (SS 304 or SS 316)
Size:
DN 10 to DN 1000 (1/8" to 40")
Temperature Range:
-196°C to +260°C (-320°F to +500°F)
Bolt Hole Diameter:
M10 x 1.5 to M100 x 14
The technical specifications of vacuum flanges are critical in ensuring their performance and reliability in high-vacuum applications. The materials, size, temperature range, and bolt hole diameter are carefully selected to meet the demanding requirements of vacuum environments.
Description Of Vacuum Flanges
Vacuum flanges are designed to provide a reliable and leak-tight connection in high-vacuum applications. They are manufactured using high-quality materials and precision machining techniques to ensure precise fits and smooth connections.
Related Products & Synonyms Of Vacuum Flanges
Vacuum flanges are related to other piping components and equipment designed for high-vacuum applications, such as:
