A flexible coupling is a mechanical device used to connect two rotating shafts, allowing for some degree of misalignment and vibration absorption. It consists of two hubs connected by a flexible element, such as a rubber or polyurethane sleeve, that can absorb angular misalignments and axial displacements.
Where To Use Flexible Coupling
Flexible couplings are commonly used in industrial applications where there is a need to connect two rotating shafts with some degree of misalignment, such as:
Power transmission systems
Machinery with vibrating or oscillating parts
Applications requiring high-speed operation
Systems with limited space for rigid couplings
Key Features Of Flexible Coupling
Flexibility in angular misalignment up to 5°
Ability to absorb axial displacements and vibrations
Compact design for space-saving applications
Durability with long lifespan
Easy installation and maintenance
How To Use Flexible Coupling
Align the shafts to be connected as closely as possible
Select the correct size and type of flexible coupling for the application
Mount the hubs securely on each shaft
Install the flexible element between the hubs, ensuring proper tension
Check and adjust the alignment of the shafts during operation
How Flexible Coupling Is Manufactured
Flexible couplings are typically manufactured using high-quality materials, such as metal or polymer, through a combination of machining and assembly processes.
Technical Specification Of Flexible Coupling
Material:
Stainless Steel
Torque Capacity:
Up to 500 Nm
Length:
120 mm
Surface Finish:
Roughened for improved grip
The material used is stainless steel, providing high strength and resistance to corrosion. The torque capacity is up to 500 Nm, making it suitable for heavy-duty applications. The length of the coupling is 120 mm, allowing for compact designs in confined spaces. The surface finish is roughened for improved grip between the hubs and the flexible element.
Description Of Flexible Coupling
Flexible couplings are designed to provide flexibility and misalignment compensation in power transmission systems, while minimizing vibration and stress on connected machinery.
Related Products & Synonyms Of Flexible Coupling
The following products are related to flexible couplings:
